Каталог запасных частей к технике: KRONE BIG-M-II. Control panel (roof)
1
2
2
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
17
18
19
19
20
21
21
21
22
23
24
25
26
26
26
27
28
29
30
31
32
33
34
35
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 002204430 | Cooler | |
| 2 | 002204400 | Air outlet | |
| 3 | 002205190 | Frame for cooler | |
| 4 | 002204491 | Gasket | |
| 5 | 002204340 | Roof console | |
| 6 | 002205170 | Frame for radio | |
| 7 | 002204390 | Sun visor | |
| 8 | 002204420 | In-cab mirrow | |
| 9 | 002204380 | Air grating | |
| 10 | 002205180 | Frame for radio-outside | |
| 11 | 002204360 | Blind cover | |
| 12 | 002205120 | Nozzle | |
| 13 | 002204010 | Spring lock | |
| 14 | 002204020 | Plate spring | |
| 15 | 002204410 | Cover for cooler | |
| 16 | 002204350 | Switch plate | |
| 17 | 002205140 | Mounting batten-end piece | |
| 18 | 002205130 | Mounting batten-intermediate piece | |
| 19 | 003025240 | Switch-ON- OFF | |
| 20 | 003025250 | Switch-warning lights | |
| 21 | 003026530 | Cover | |
| 22 | 003025330 | Mirror switch | |
| 23 | 003033590 | Combi-switch | |
| 24 | 003033600 | Combi-switch | |
| 25 | 003028050 | Switch | |
| 26 | 003033550 | Switch symbol | |
| 27 | 003033560 | Switch symbol-green | |
| 28 | 003033530 | Switch symbol-yellow | |
| 29 | 003033540 | Switch symbol-red | |
| 30 | 003033580 | Switch symbol | |
| 31 | 003033570 | Switch symbol | |
| 32 | 002204370 | Frame for radio cut-out | |
| 33 | 002205830 | Baffle-left | |
| 34 | 002205820 | Cellofoam-ring | |
| 35 | 002205840 | Baffle-right |
